Overview
Built to handle large data volumes efficiently, the 1768-ENBT/A offers enhanced communication throughput and flexible configuration options. In addition, it supports multiple simultaneous connections, enabling system engineers to design scalable and responsive automation systems with minimal latency.
Specification
| Parameter | Specification |
|---|---|
| Product Type | EtherNet/IP Communication Module |
| Catalog Number | 1768-ENBT/A |
| Network Protocol | EtherNet/IP |
| Communication Rate | 10/100 Mbps (auto-negotiation) |
| Number of Connections | Up to 128 TCP and 64 CIP |
| Supported Controllers | CompactLogix L4X and GuardLogix |
| Power Supply | 24 VDC (via CompactLogix backplane) |
| Power Consumption | Approximately 2.5 W |
| Operating Temperature | 0 °C to +60 °C |
| Storage Temperature | -40 °C to +85 °C |
| Relative Humidity | 5–95%, non-condensing |
| Mounting Method | DIN rail or chassis |
| Diagnostics | Module and network status LEDs |
| Configuration Software | RSLogix 5000 / Studio 5000 |
| Dimensions (W x H x D) | 35 mm x 118 mm x 87 mm (approx.) |
| Weight | 0.25 kg (approx.) |
| Enclosure Rating | Open-type, for use in an enclosure |
| Certifications | CE, UL, cUL, C-Tick, KC |
FAQ
A1: It works seamlessly with CompactLogix L4X and GuardLogix controllers.
Q2: How fast is the communication rate?
A2: The module supports 10/100 Mbps full-duplex Ethernet communication.
Q3: Can it be configured through RSLogix 5000?
A3: Yes, configuration and diagnostics are available through RSLogix 5000 or Studio 5000 software.
Q4: What is the maximum number of supported connections?
A4: It supports up to 128 TCP and 64 CIP connections simultaneously.
Q5: Does the module have LED indicators?
A5: Yes, it includes module and network LEDs for quick status monitoring.
