Overview
Specification
| Parameter | Specification |
|---|---|
| Brand | Rockwell Automation / Allen-Bradley |
| Model Number | 1492-CABLE005Z |
| Module Type | CompactLogix Digital Cable Connection Module |
| System Compatibility | Allen-Bradley CompactLogix digital I/O modules |
| Connector Type | Multi-pin locking connector for secure connection |
| Cable Type | Shielded digital cable for EMI/RFI protection |
| Number of Conductors | 5 conductors for digital signals and ground |
| Conductor Material | Tinned copper wires for low-resistance connections |
| Insulation Material | High-performance PVC or equivalent polymer |
| Cable Shielding | Braided copper shield with foil layer |
| Cable Jacket | Flame-retardant, oil-resistant polymer |
| Cable Length | Standard 0.5 m (custom lengths available) |
| Operating Temperature Range | -40°C to 70°C (-40°F to 158°F) |
| Storage Temperature Range | -40°C to 85°C (-40°F to 185°F) |
| Voltage Rating | 300 V AC/DC maximum |
| Current Rating | 3 A maximum per conductor |
| Certifications | UL Listed, CE Marked, RoHS Compliant |
| Mounting Type | Panel or rack-mounted with quick-connect interface |
| Key Features | Compact design, high signal integrity, easy installation |
| Environmental Protection | Resistant to dust, oil, and industrial contaminants |
FAQ
A1: It is compatible with most CompactLogix digital I/O modules; always confirm module-specific requirements before installation.Q2: Can the cable length be customized?
A2: Yes, Rockwell Automation provides custom-length cables to fit specific installation layouts.
Q3: How does this module handle electrical interference?
A3: The braided copper and foil shielding offer excellent EMI/RFI protection, ensuring reliable digital signal integrity.
Q4: What is the operating temperature range?
A4: The module operates reliably between -40°C and 70°C and resists dust, oil, and other industrial contaminants.
Q5: How can I maintain or troubleshoot the module?
A5: Minimal maintenance is required. Inspect connectors and shielding periodically. ControlLogix diagnostics assist with troubleshooting any issues.
