Overview
The Honeywell 8U-PWSP04 is a 24VDC/20A power supply module designed for the Experion C300 Controller, part of the Series 8 I/O system. Manufactured by PULS, this module ensures reliable power delivery to Experion I/O modules, supporting both standard and redundant configurations.
Commercial Off the Shelf (COTS) power system for Series-8 is available when Battery Backup is not required. The COTS Power system provides redundant 24VDC primary power at 20 amps for Series 8 devices. The power system also provides capabilities to support integral field power. This eliminates the need for additional
power sources as well as the additional wiring, fusing, marshalling and documentation costs. Various COTS power systems are available. Selection is a user preference.
Specification
| Parameter | Specification |
|---|---|
| Model Number | 8U-PWSP04 |
| Manufacturer | Honeywell (PULS) |
| Output Voltage | 24V DC |
| Output Current | Up to 20A |
| Maximum Power Output | 480W |
| Efficiency | 92.7% |
| Input Voltage Range | 85–276 VAC |
| Operating Temperature | –20°C to +60°C |
| Storage Temperature | –40°C to +85°C |
| Dimensions (WxHxD) | 3 cm × 31.3 cm × 27.8 cm |
| Weight | 0.56 kg |
| Protection Features | Overcurrent, overvoltage, thermal protection |
| Compliance Standards | CE, UL |
Manual/Datasheet PDF
Honeywell Series 8 Controller and IO Specification
