Overview
The Honeywell 8C-TPOXA1 is an Input/Output Terminal Assembly (IOTA) designed to facilitate communication between the Experion C300 Controller and PROFIBUS DP networks. This module serves as a PROFIBUS Gateway, enabling seamless integration of PROFIBUS devices into Honeywell’s Series 8 I/O systems.
Specification
| Parameter | Specification |
|---|
| Model Number | 8C-TPOXA1 |
| Manufacturer | Honeywell |
| Type | I/O Terminal Assembly (IOTA) (64pt) PWA |
| Communication Protocol | PROFIBUS DP (RS485) |
| Transmission Speed | Up to 12 Mbps |
| Power Supply | Powered via rear panel of I/O chassis |
| Voltage Rating | 24 VDC |
| Module Current Rating | 430 mA |
| Mounting | Standard Series 8 carrier assembly |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Dimensions (WxHxD) | 12.4 cm x 12.6 cm x 2.2 cm |
| Weight | Approximately 0.48 kg |
Manual/Datasheet PDF
8C-TPOXA1 Honeywell C300 IOTA (64pt) PWA datasheet
