Overview
The Honeywell 8C-TAID61 51307069-175 is an analog input module designed to receive field signals for processing by an industrial control system. Its documented features include 16 input channels, open wire detection, extensive self-diagnostics, and optional redundancy. The module also supports non-incendive field power, making the applicable field wiring and power requirements important considerations during configuration.
Key Features
- 16-channel analog input: Receives analog signals from connected field devices for monitoring and control.
- Open wire detection: Helps identify open-circuit conditions in supported input circuits.
- Extensive self-diagnostics: Supports internal fault detection and module status monitoring.
- Optional redundancy: Provides a redundancy option where supported by the system configuration.
- Non-incendive field power: Supports the specified non-incendive field power function. Confirm the applicable field wiring requirements before use.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | 8C-TAID61 51307069-175 |
| Spare Model | 51307069-175 |
| Brand | Honeywell |
| Product Type | Analog Input Module |
| Input Channels | 16 |
| Input Impedance | 250 ohm |
| Power Supply | 5 V DC |
| Power Consumption | 4-12 W |
| Isolation | 1500 V AC |
| Diagnostic Functions | Extensive self-diagnostics |
| Open Wire Detection | Supported |
| Redundancy | Optional |
| Field Power | Non-incendive field power |
| Operating Temperature | -20 to +70 deg C |
| Storage Temperature | -40 to +85 deg C |
| Humidity | 5-95% RH, non-condensing |
| Manufacturer | Honeywell |
| Country of Origin | USA |
| Estimated Shipping Size | 29.5 x 12 x 7.5 cm |
| Weight | 0.42 kg |
| HS Code | 8537101190 |
Input Monitoring and Diagnostics
The 8C-TAID61 receives analog input signals through its 16 channels. Its 250 ohm input impedance is a relevant parameter when checking the electrical requirements of connected field devices and signal circuits. The specific supported signal ranges and input types are not confirmed in the available specifications, so these should be verified before selecting field transmitters or finalizing wiring.
Open wire detection and self-diagnostics help identify certain wiring faults and internal module conditions. Actual detection coverage depends on the supported input configuration and diagnostic capabilities.
Redundancy and Field Power
The module supports optional redundancy, but the applicable redundant arrangement and required companion hardware are not specified here. Confirm the system configuration before replacing a module or planning a redundant installation.
The listed non-incendive field power feature should also be considered when checking field-device connections. Do not assume that it establishes suitability for every hazardous location or field circuit; verify the relevant system and installation requirements.
