Overview
Specification
| Parameter | Specification |
|---|---|
| Model Number | 5501-367 |
| Module Type | Micronet Simplex LV Discrete Module |
| Power Supply | 24 VDC nominal, 0.5 A typical |
| Input Type | Low-voltage discrete signals, 24 VDC logic level |
| Output Type | Discrete control signals, open-collector or relay-compatible |
| Communication Interface | WOODWARD Micronet digital network |
| Number of Channels | 16 discrete input channels, 16 discrete output channels |
| Response Time | < 5 ms typical for discrete I/O |
| Isolation | Optical isolation between input, output, and power |
| Operating Temperature | 0°C to +70°C |
| Storage Temperature | –40°C to +85°C |
| Humidity | 5–95% RH non-condensing |
| Mounting | Rack-mounted Micronet slot |
| LED Indicators | Power, status, and I/O activity indicators |
| Reliability | MTBF > 100,000 hours, designed for continuous industrial operation |
| Regulatory Compliance | CE, UL recognized component |
| Typical Applications | Engine and turbine control, industrial automation systems |
| Dimensions | 7.5 x 2.5 x 5 inches (rack module size) |
| Connector Type | 50-pin rack edge connector |
| Electrical Protection | Over-voltage and short-circuit protection on I/O lines |
| Signal Voltage | 24 VDC nominal, input range 20–28 VDC |
| Sampling Rate | 1 kHz digital scan frequency |
FAQ
A1: It provides precise low-voltage discrete input and output control for engine and turbine systems.
Q2: Can it integrate with other WOODWARD control systems?
A2: Yes, it fully supports Micronet digital network integration.
Q3: What is the operational temperature range?
A3: It operates reliably from 0°C to +70°C in standard industrial environments.
Q4: Is the module suitable for harsh industrial conditions?
A4: Yes, the robust construction allows continuous operation in demanding environments.
