Overview
Specification
| Parameter | Description |
|---|---|
| Model | 5466-353 |
| Manufacturer | Woodward |
| Module Type | Netcon Main Chassis TR Transceiver Module |
| Function | Signal conversion and transmission interface |
| Compatibility | Woodward Netcon control systems |
| Mounting Type | Plug-in to main chassis backplane |
| Communication Type | High-speed transceiver |
| Isolation | Galvanic isolation between communication channels |
| Input Voltage | 18–32 VDC nominal |
| Operating Temperature | -40°C to +70°C |
| Storage Temperature | -55°C to +85°C |
| Cooling | Convection-cooled, fanless |
| Indicators | Status LEDs for power and communication health |
| Construction | Industrial-grade PCB with conformal coating |
| Compliance | CE, UL, and marine certifications (where applicable) |
FAQ
A1: It acts as a transceiver interface for high-speed data communication within Netcon control systems.Q2: Is this module compatible with older Netcon chassis versions?
A2: Yes. It is designed for backward compatibility with most Netcon main chassis configurations.
Q3: Can the module operate in high-temperature environments?
A3: Yes. It supports reliable performance from -40°C to +70°C.
Q4: How can I identify communication faults?
A4: The module provides front-panel LED indicators for communication and power status, helping users diagnose issues quickly.
