Overview
Therefore, users benefit from faster response times, predictable system behavior, and superior operational uptime. With its compact, standalone design and intelligent redundancy, the 3701/55 offers a powerful and flexible platform for achieving true machinery protection without compromise.
Specification
| Parameter | Specification |
|---|---|
| Model | 3701/55 ADAPT Overspeed ES Monitor |
| Part Number | 323073-01 |
| Module Type | ADAPT ESD 4-Channel Relay Output Module |
| System Type | Triple Modular Redundant (TMR) Safety PLC |
| Speed Input Channels | 6 total (2 per CPU module) |
| Discrete Inputs (DI) | 32 total (12 configurable as 4–20 mA analog inputs) |
| Analog Inputs (AI) | Up to 12 (shared with DI channels) |
| Relay Outputs (RO) | 4 programmable relays + 1 dedicated trip relay per module |
| Relay Type | Form C (SPDT) electromechanical relays |
| Contact Rating | 5 A at 30 VDC or 250 VAC resistive load |
| Communication Interface | Ethernet / Modbus TCP |
| Programming Interface | Graphical Logic Programming (ADAPT Workbench) |
| Power Supply | 24 VDC nominal |
| System Redundancy | Triple Modular Redundant (TMR) |
| Operating Temperature | -20°C to +65°C |
| Storage Temperature | -40°C to +85°C |
| Certifications | SIL 3 (IEC 61508), API 670 compliant |
| Mounting | Panel mount |
| Enclosure Type | Industrial, metal chassis |
| Typical Application | Overspeed protection, trip relay actuation, system logic output |
| Compatibility | Works with Bently Nevada ADAPT ESD and Overspeed Systems |
| Agency Approvals | CE, ATEX, IECEx (varies by configuration) |
| Weight | Approx. 1.2 kg (2.6 lb) |
FAQ
Q1: What does TMR mean in the 3701/55 system?
A1: TMR stands for Triple Modular Redundancy, where three processors simultaneously perform computations. The system votes among results to detect and isolate any fault, ensuring continued safe operation.
Q2: Can the ADAPT ESD be integrated with DCS or PLC systems?
A2: Yes. It supports standard communication protocols like Modbus TCP, allowing seamless integration with distributed control and safety systems.
Q3: Is the 3701/55 suitable for SIL 3 applications?
A3: Absolutely. The device is certified to SIL 3 under IEC 61508, making it suitable for high-integrity safety functions in turbomachinery control.
Q4: How many overspeed channels are supported?
A4: The system processes six speed input channels—two per CPU module—providing high-speed, redundant overspeed protection.
Manual/Datasheet PDF
