Overview
Constructed from high-strength glass-reinforced Polyphenylene Sulfide (PPS) thermoplastic, the housing resists corrosion and maintains structural integrity under industrial conditions. Furthermore, stainless steel sleeves, retaining chains, and exterior screws provide added durability. Therefore, engineers can rely on this assembly for turbines, compressors, and other rotating machinery, even when exposed to harsh environmental conditions.
Designed to comply with API 670 standards, this housing assembly supports intrinsically safe installations when paired with approved transducer systems and I.S. barriers. In addition, its CSA and IP66/NEMA 4X certifications confirm suitability for hazardous and wet environments. Consequently, the 31000 series combines reliability, precision, and ease of maintenance for industrial vibration monitoring applications.
Specification
| Parameter | Specification |
|---|---|
| Model | 31000-28-10-00-020-03-02 |
| Product Type | Proximity Probe Housing Assembly |
| Housing Material | Glass-reinforced Polyphenylene Sulfide (PPS) thermoplastic |
| Sleeve Material | AISI 304 stainless steel |
| Outer Sleeve & Screws | AISI 303 stainless steel |
| O-Ring Material | Neoprene |
| Probe Compatibility | 3300 XL 8 mm proximity probe, multiple approvals |
| Probe Cable Length | 1.0 m (39 in) |
| Environmental Rating | CSA Type 4X, IP66/NEMA 4X, EN50014 electrostatic dissipation compliant |
| Temperature Range | -51 °C to +105 °C (-60 °F to +221 °F) |
| Hot Water / Steam Exposure | Up to 1 week exposure at 95 °C (203 °F) without significant strength loss |
| Recommended Torque (Retaining Nut) | 29.4 N·m (260 in·lb) |
| Housing Strength | Supports 912 N (205 lb) at 38 mm (1.5 in) from unsupported end |
| Housing Impact Strength | Certified for 4 Joule impact at -39 °C & 115 °C; 7 Joule at ambient |
| Weight | 1.2 kg (2.6 lb) typical |
| Fittings | Without fittings |
| Mounting Thread Option | 3/4-14 NPT (Required if ordering Standoff Adapter Option) |
FAQ
A1: It is compatible with Bently Nevada 3300 XL 8 mm proximity probes for accurate radial vibration measurement.
Q2: Can this housing be used in hazardous areas?
A2: Yes, when installed with approved transducers and I.S. barriers, it supports intrinsically safe applications.
Q3: What environmental conditions can this assembly withstand?
A3: It is CSA Type 4X, IP66/NEMA 4X rated, with temperature range from -51 °C to +105 °C and resistance to short-term hot water or steam exposure.
Q4: Does this housing allow probe replacement without disassembling machinery?
A4: Yes, external access to the probe and cable enables gap adjustments or replacements without machine disassembly.
