Overview
With support for high-speed data transfer and real-time monitoring, this module enhances overall plant efficiency and ensures smooth communication between controllers and remote devices.
Specification
| Category | Specification |
|---|---|
| Manufacturer | Schneider Electric |
| Range of Product | Modicon Quantum |
| Model | 140NOE77100 |
| Module Type | Ethernet Network TCP/IP Module |
| Ethernet Ports | 2 x RJ45 10/100 Mbps |
| Protocol Support | TCP/IP, Modbus TCP, Class B20 |
| Configuration Software | Rack Viewer, Data Editor |
| Power Supply | 5 V DC from backplane |
| Power Consumption | 2.5 W typical |
| Operating Temperature | 0–60°C |
| Storage Temperature | -20–70°C |
| LED Indicators | Link, Activity, Status |
| Isolation | No isolation on data lines |
| Dimensions | Standard Modicon Quantum module size |
| Weight | 0.12 kg |
| Compliance | CE, UL, IEC standards |
FAQ
Q1: Is the 140NOE77100 an original Schneider product?
A1: Yes, it is brand new, factory-sealed, and fully original from Schneider.
Q2: How fast can I receive the module after ordering?
A2: Shipping typically occurs within 3 days to 2 weeks depending on order size, via DHL or similar services.
Q3: Can this module support redundant network topologies?
A3: Yes, the dual RJ45 ports allow flexible network configurations including redundancy.
Q4: What is the power requirement for this module?
A4: It draws 5 V DC from the Modicon Quantum backplane, consuming approximately 2.5 W.
Q5: What should I do if there is a quality issue?
A5: We provide a 30-day return policy for any quality-related concerns.
