Overview
Specification
| Parameter | Specification |
|---|---|
| Model | 140DRC83000 |
| Brand | Schneider Electric |
| Module Type | Relay discrete output module for Quantum PLC systems |
| Number of Output Channels | 8 independent relay outputs |
| Output Type | Form C (SPDT) electromechanical relays |
| Rated Voltage | 24–230 V AC/DC, suitable for a wide range of control circuits |
| Maximum Switching Current | 2 A per channel for reliable load control |
| Minimum Switching Current | 10 mA, ensuring precise low-current operation |
| Terminal Type | Screw terminals for secure and easy wiring |
| Rack Compatibility | Compatible with Modicon Quantum standard and extended racks |
| Operating Temperature | 0–60°C (32–140°F) for industrial environments |
| Storage Temperature | -20–70°C for safe module storage and transport |
| Mounting | DIN rail or rack-mounted for flexible installation |
| LED Status Indicators | Individual channel LEDs for easy monitoring and diagnostics |
| Isolation | Full isolation between input and output circuits |
| Response Time | Typical 10–15 ms switching time for fast operations |
| Certifications | CE, UL, and CSA compliant for industrial safety standards |
FAQ
It provides eight independent relay outputs for versatile control applications.
Q2: What voltage range can the relays handle?
The module supports 24–230 V AC/DC for discrete outputs.
Q3: Is the module compatible with Quantum racks?
Yes, it integrates fully with all standard Modicon Quantum racks.
Q4: Are there diagnostic indicators on the module?
Yes, LEDs provide status information for each output channel.
Q5: Can it operate in harsh industrial environments?
Yes, it is rated for 0–60°C and designed for industrial conditions.
