Overview
Designed for demanding industrial and substation environments, the UR-6EH supports 4 form-C digital outputs and 8 digital inputs, delivering accurate and reliable relay automation. In addition, it integrates smoothly with other UR Series modules, enhancing system flexibility, reliability, and operational continuity. Therefore, this module is ideal for substations, industrial control networks, and applications requiring high-speed digital I/O performance.
Specification
| Parameter | Specification |
|---|---|
| Model | UR-6EH |
| Manufacturer | GE Fanuc Multilin |
| Module Type | Digital I/O Module for UR Series |
| Input Channels | 8 digital inputs (dry contact or voltage input) |
| Output Channels | 4 form-C relay outputs |
| Operating Voltage | 125 VDC nominal (100–140 VDC range) |
| Power Consumption | 8 W typical |
| Communication Interface | UR proprietary backplane bus |
| Relay Logic Execution | High-speed execution for real-time operations |
| Diagnostics | LED indicators for power, module status, and faults |
| Operating Temperature | -40°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5–95% RH, non-condensing |
| Vibration & Shock | IEC 60255 compliant |
| Mounting | Plug-in module compatible with UR chassis |
| Redundancy Support | Compatible with redundant UR system configurations |
| Hot-Swap Capability | Yes |
| Compliance | IEC 60255, UL listed, CE marked |
| Dimensions | Approx. 150 mm (H) × 50 mm (W) × 120 mm (D) |
| Weight | 0.75 kg |
FAQ
A1: Yes, the module can be replaced while the system remains powered, minimizing operational downtime.
Q2: How many digital inputs and outputs does the UR-6EH support?
A2: The module provides 8 digital inputs and 4 form-C relay outputs for versatile control.
Q3: What environmental conditions can the UR-6EH withstand?
A3: It operates reliably between -40°C and +70°C with 5–95% non-condensing humidity.
Q4: Can the UR-6EH integrate with other UR Series modules?
A4: Yes, it seamlessly interfaces with UR Series CPU, CT/VT, and power modules for system-wide control.
Q5: What diagnostics features does the UR-6EH include?
A5: Built-in LED indicators display module status, power, and fault conditions for fast troubleshooting.
