Overview
Engineered for demanding industrial and power environments, the UR-6TH supports high-speed relay logic execution with dependable performance. In addition, it integrates seamlessly with other UR Series modules, including CT/VT, power, and CPU modules, providing flexible system configuration and enhanced operational reliability. Therefore, it is an ideal choice for substations, industrial automation networks, and mission-critical applications.
Specification
| Parameter | Specification |
|---|---|
| Model | UR-6TH |
| Manufacturer | GE Fanuc Multilin |
| Module Type | Digital I/O Module for UR Series |
| Operating Voltage | 125 VDC nominal (100–140 VDC range) |
| Power Consumption | 10 W typical |
| Input/Output Channels | 16 digital inputs / 16 digital outputs (typical) |
| Communication Interface | UR proprietary backplane bus |
| Relay Logic Execution | Supports multiple high-speed relay logic routines |
| Diagnostics | LED indicators for module health, power, and communication |
| Operating Temperature | -40°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5–95% RH, non-condensing |
| Vibration & Shock | IEC 60255 compliant |
| Mounting | Plug-in module compatible with UR chassis |
| Redundancy Support | Compatible with redundant UR system configurations |
| Hot-Swap Capability | Yes |
| Compliance | IEC 60255, UL listed, CE marked |
| Dimensions | Approx. 150 mm (H) × 50 mm (W) × 120 mm (D) |
| Weight | 0.75 kg |
FAQ
A1: Yes, the module is hot-swappable, allowing replacement without shutting down the system.
Q2: Which UR modules are compatible with UR-6TH?
A2: It integrates with all UR Series modules, including CPU, CT/VT, and power modules.
Q3: What environmental conditions can UR-6TH withstand?
A3: The module operates reliably in temperatures from -40°C to +70°C and up to 95% non-condensing humidity.
