Overview
The Honeywell MU-TDID52 51304441-200 is a digital input module designed to monitor discrete electrical signals in an industrial control system. It provides 32 input channels for detecting field signal states. The supplied specifications list an input range of 24 VDC to 230 VAC and an input response time of less than 5 ms. These details help identify the module and assess its signal monitoring requirements.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | MU-TDID52 |
| Part Number | 51304441-200 |
| Brand | Honeywell |
| Product Type | Digital Input Module |
| Number of Input Channels | 32 |
| Input Voltage Range | 24 VDC to 230 VAC |
| Input Response Time | Less than 5 ms |
| Isolation Voltage | 1500 Vrms |
| Communication Protocol | Modbus RTU |
| Power Consumption | Less than 2 W per channel |
| Dimensions | 120 mm x 60 mm x 40 mm |
| Weight | 0.57 kg |
Digital Input Function
Digital input modules monitor discrete electrical signals and make their states available to a control system. Depending on the field device and input circuit, these signals can represent conditions such as a switch position, contact status, or equipment running state. The 32-channel configuration provides multiple input points in one module.
Signal Range and Response Time
The stated input voltage range covers both 24 VDC and AC signals up to 230 VAC. However, the supported input types, threshold levels, channel grouping, and wiring arrangements require confirmation before connecting field devices. The specified response time of less than 5 ms describes the stated input response limit; the complete system detection time may also depend on controller processing and communication updates.
Frequently Asked Questions
Q: How many digital input channels does the MU-TDID52 provide?
A: The supplied specifications list 32 input channels. Confirm the channel wiring and electrical requirements before assigning field signals.
Q: Can the MU-TDID52 accept both AC and DC input signals?
A: The supplied data lists an input voltage range of 24 VDC to 230 VAC. The exact supported voltage levels and input circuit configuration should be verified against the module’s technical documentation before installation.
Q: Is the MU-TDID52 confirmed to use Modbus RTU?
A: The supplied information lists Modbus RTU as the communication protocol. This detail has not been independently verified for part number 51304441-200, so confirm the interface and system connection requirements before selecting the module.
