Overview
The Honeywell MU-TDOD52 51304423-200 is a digital output module specified for industrial automation and control applications. It provides 16 output channels for controlling digital signals between a control system and connected field devices. The supplied specifications list a 24 VDC input voltage and a response time of less than 10 ms. Confirm the electrical output characteristics and communication interface before selecting the module for a specific system.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | MU-TDOD52 |
| Part Number | 51304423-200 |
| Brand | Honeywell |
| Product Type | Digital Output Module |
| Input Voltage | 24 VDC |
| Output Channels | 16 |
| Response Time | Less than 10 ms |
| Communication Protocol | Modbus RTU |
| Operating Temperature | -40 to +70 deg C |
| Dimensions | 120 x 80 x 35 mm |
| Weight | 0.6 kg |
Signal Control and Configuration
A digital output module controls discrete signal states according to commands from a control system. Its 16-channel configuration provides multiple output points for connected devices. However, the output voltage range, output current rating, switching type, and channel isolation are not specified here. Verify these characteristics against the module’s applicable technical documentation before connecting field loads.
Frequently Asked Questions
Q: How many output channels does the MU-TDOD52 provide?
A: The supplied specifications list 16 output channels. The electrical ratings and wiring requirements for each channel require further verification.
Q: What power supply does this module require?
A: The supplied data lists 24 VDC as the input voltage. Confirm the power connection requirements and permitted voltage range before installation.
Q: Does the MU-TDOD52 support Modbus RTU communication?
A: The supplied data identifies Modbus RTU as the communication protocol. The physical interface, communication settings, and compatibility with a particular controller have not been confirmed.
