Overview
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | VE4036P2 |
| Brand | Emerson |
| Product Type | Redundant M-Series Serial Interface Card |
| Origin | USA |
| Weight | 0.2 kg |
| Dimensions | 4.2 cm x 12.5 cm x 10.5 cm |
| Communication Ports | 2 serial ports |
| Communication Type | Serial Interface |
| Data Bits | 7 or 8 |
| Stop Bits | 1 or 2 |
DCS Serial Communication and Protocol Interface
The VE4036P2 provides serial communication channels for DeltaV M-Series architectures. The card supports configurable serial frame parameters, including 7-bit or 8-bit data formats and 1-bit or 2-bit stop configurations.
For Emerson process control applications, the module interfaces with external serial devices while maintaining DeltaV communication architecture requirements. In addition, the interface design supports integration of serial field equipment where direct data exchange is required.
The VE4036P2 belongs to the Emerson DeltaV process control hardware family, which commonly supports industrial communication methods such as 4-20 mA HART loop protocol, FOUNDATION Fieldbus, and Profibus PA connectivity through dedicated DeltaV I/O hardware. This specific module is configured for serial interface communication rather than analog or fieldbus termination.
Frequently Asked Questions
Q: What communication function does the Emerson VE4036P2 provide?
A: The VE4036P2 provides two serial communication ports for exchanging data between DeltaV M-Series systems and connected serial devices.
Q: Which serial frame settings are supported by the VE4036P2?
A: The module supports selectable data bit configurations of 7 or 8 bits and stop bit configurations of 1 or 2 bits.
Q: Is the VE4036P2 designed for redundant system configurations?
A: Yes. The VE4036P2 is identified as a redundant M-Series serial interface card and is intended for DeltaV M-Series redundant interface applications.
Field Installation Guidelines
- Verify the DeltaV M-Series hardware compatibility before installation.
- Install the card according to Emerson DeltaV chassis slot allocation requirements.
- Confirm serial cable pin assignments before connecting external devices.
- Use shielded communication cables where required by the installation environment.
- Connect cable shields according to site grounding practices to reduce electrical interference.
- Check serial communication parameters, including data bits and stop bits, before system commissioning.
