Specification
| Parameter | Specification |
|---|---|
| Part Number | KC3020X1-BA2 |
| Module Type | DO 32-Ch 24VDC High-Side Plus Card |
| Output Channels | 32 High-Side 24 VDC |
| Local Bus Power | 12 VDC at 150 mA |
| Bussed Field Power | 24 VDC at 3.2 A per card |
| Field Circuit Output | 24 VDC at 100 mA per channel |
| Ambient Temperature | -40 °C to +70 °C |
| Shock | 10 g half-sine wave, 11 ms |
| Vibration | 1 mm peak-to-peak 2–13.2 Hz; 0.7 g 13.2–150 Hz |
| Humidity | 5–95% non-condensing |
| Airborne Contaminants | ISA-S71.04 Class G3 |
| Hazardous Area Approvals | ATEX II 3G Ex ec nC IIC Gc, IECEx, FM, CL. I Div.2, Zone 2 |
| Maintenance | No user-serviceable parts; calibration not required |
| Installation | Remove field power before insertion or removal |
| Terminal Block Keying | Rotary key system ensures correct I/O card matching |
FAQ
A1: The card provides 32 high-side 24 VDC output channels for reliable control of field devices.Q2: Is this card suitable for hazardous areas?
A2: Yes, it is certified for ATEX, IECEx, FM, Class I Div.2, and Zone 2 operation.
Q3: What is the operating temperature range?
A3: The card operates reliably from -40 °C to +70 °C under industrial conditions.
Q4: Does the card require calibration or user maintenance?
A4: No, calibration is not required, and there are no user-serviceable parts, minimizing maintenance.
Q5: How should the card be installed or removed safely?
A5: Field power must be removed before inserting or removing the card to ensure safety.
Q6: How resistant is the card to shock and vibration?
A6: It withstands 10 g shock and vibration up to 1 mm peak-to-peak or 0.7 g, meeting industrial standards.
