| Parameter | Specification |
|---|---|
| Part Number | KJ3002X1-BG1 |
| Module Type | 2-Wire AI 8-Channel 4-20 mA HART Card |
| Analog Input Channels | 8 independent 2-wire channels |
| Input Signal Range | 4–20 mA HART |
| Input Impedance | 250 Ω nominal |
| Accuracy | ±0.1% of span |
| Update Rate | 100 ms per channel |
| Ambient Temperature | -40 °C to +70 °C |
| Shock Resistance | 10 g half-sine wave, 11 ms |
| Vibration Resistance | 1 mm peak-to-peak 2–13.2 Hz; 0.7 g 13.2–150 Hz |
| Humidity | 5–95% non-condensing |
| Airborne Contaminants | ISA-S71.04 Class G3 |
| Hazardous Area Approvals | ATEX, IECEx |
| Maintenance | No user-serviceable parts; calibration not required |
| Installation | Plug-in design for DeltaV remote I/O racks |
FAQ
A1: It supports 8 independent 2-wire 4–20 mA HART channels for field device measurement.
Q2: Can this card operate in hazardous areas?
A2: Yes, it complies with ATEX and IECEx hazardous area standards.
Q3: What is the operating temperature range?
A3: The card operates reliably between -40 °C and +70 °C.
Q4: Does the card require calibration?
A4: No, calibration is not required and there are no user-serviceable parts.
Q5: How accurate are the measurements?
A5: The card provides ±0.1% of span accuracy across the 4–20 mA range.
Q6: How does the card handle vibration and shock?
A6: It withstands 10 g shock and 1 mm peak-to-peak vibration per industrial standards.
