Overview
Specification
| Parameter | Specification |
|---|---|
| Part Number | KL2101X1-BB1 |
| Module Type | Remote I/O Master Unit |
| Compatible I/O | CHARM I/O Cards (CIOC2) |
| Input Power | 24 VDC at 2 A max |
| Output Power | 6.3 VDC at 3.25 A |
| Operating Temperature | -40 °C to +70 °C |
| Shock Resistance | 10 g half-sine wave, 11 ms |
| Vibration Resistance | 1 mm peak-to-peak 2–13.2 Hz; 0.7 g 13.2–150 Hz |
| Humidity | 5–95% non-condensing |
| Airborne Contaminants | ISA-S71.04 G3 |
| Hazardous Area Approvals | ATEX, IECEx, FM, Class I Div.2, Zone 2 |
| Maintenance | No user-serviceable parts; calibration not required |
| Mounting | Panel or rack integration |
FAQ
A1: It is compatible with DeltaV CHARM I/O cards, including CIOC2 modules.
Q2: What are the power requirements?
A2: Input is 24 VDC at 2 A max, and output is 6.3 VDC at 3.25 A.
Q3: Can this unit operate in hazardous areas?
A3: Yes, it holds ATEX, IECEx, and FM approvals for Zone 2 and Class I Div.2.
Q4: What is the operating temperature range?
A4: The unit operates reliably from -40 °C to +70 °C.
Q5: Is calibration required for this module?
A5: No, calibration is not required and there are no user-serviceable parts.
Q6: How does it handle industrial stress like vibration or shock?
A6: The unit is resistant to 10 g shock and industrial vibration per specifications.
