Overview
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | F2201 |
| Brand | HIMA |
| Product Type | CPU Board |
| Microcontroller | 16-bit |
| Clock Speed | 20 MHz |
| RAM | 128 KB |
| Flash Memory | 1 MB |
| Power Supply | 24 VDC |
| Maximum Current | 2.5 A |
| Operating Temperature | -20 to +70 deg C |
| Storage Temperature | -40 to +85 deg C |
| Relative Humidity | 5-95% RH, non-condensing |
| Weight | 0.16 kg |
| Estimated Shipping Dimensions | 19.8 x 14.2 x 2.5 cm |
| Country of Origin | Germany |
| HS Code | 8537101190 |
Processing and Memory
The F2201 uses a 16-bit microcontroller with a 20 MHz clock to execute its supported control and processing tasks. Its 128 KB of RAM provides working memory for active operations, while the 1 MB flash memory provides non-volatile storage. The available specifications do not identify the firmware architecture or application memory allocation.
Power Requirements
The board requires a nominal 24 VDC power supply. The listed maximum current is 2.5 A; however, this figure should not be treated as a confirmed continuous operating current without further documentation. Check the equipment power supply capacity and the board’s electrical requirements before installation or replacement.
Environmental Conditions
The specified operating temperature range is -20 to +70 deg C. For storage, the permitted range is -40 to +85 deg C. Relative humidity must remain between 5% and 95% without condensation. These limits help determine whether the board’s storage and operating environment meets the stated requirements.
Frequently Asked Questions
Q: What is the main function of the HIMA F2201?
A: The F2201 is a CPU board built around a 16-bit microcontroller. Its processing and memory resources support the functions defined by its intended hardware and firmware configuration.
Q: What power supply does the F2201 require?
A: The listed supply voltage is 24 VDC, with a maximum current rating of 2.5 A. Verify the actual load requirements and power connections against the applicable equipment documentation.
Q: What should I check before replacing an F2201 board?
A: Confirm the complete F2201 model designation, board revision, firmware requirements, connector arrangement, and host-system compatibility. The specifications provided do not establish interchangeability with other HIMA boards.
