Overview
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | VE3051C0 |
| Spare Model | KJ4001X1-BA3 12P3378X012 |
| Brand | Emerson |
| Product Type | Carrier Module |
| System Platform | Emerson DeltaV I/O System |
| Origin | USA |
| Weight | 0.25 kg |
| Dimensions | 17.8 x 9.3 x 4 cm |
| Operating Temp | -40 to 70 deg C |
| Power Consumption | 30 VDC input, 8 A maximum |
| Input Voltage | 30 VDC |
| Maximum Current Capacity | 8 A |
| Mechanical Shock | 10 g half sinewave for 11 msec |
| Vibration | 1 mm peak to peak from 5 to 16 Hz |
| Airborne Contaminants | Class G3 |
| Relative Humidity | 5 to 95% non-condensing |
| Protection Rating | IP20 |
| Module Width | 2 wide carrier module |
| Mounting Function | Provides physical carrier support and electrical connection for DeltaV I/O modules |
Emerson DeltaV Carrier Power and Backplane Interface
The VE3051C0 carrier module supports DeltaV distributed I/O hardware installation by providing module positioning and DC power distribution paths. Furthermore, the carrier structure maintains electrical continuity between installed I/O components and the system backplane interface.
The module operates with a 30 VDC supply input and supports a maximum current load of 8 A. Therefore, installation requires correct power distribution planning to maintain the specified electrical loading conditions.
The Emerson DeltaV architecture emphasizes deterministic module communication and controlled field signal processing. However, the VE3051C0 functions as a carrier hardware element rather than a signal acquisition or communication processor.
Frequently Asked Questions
Q: What is the primary function of the Emerson VE3051C0?
A: The VE3051C0 functions as a DeltaV carrier module that provides mechanical mounting and electrical connection for compatible I/O modules.
Q: Does the VE3051C0 process field input or output signals?
A: No. The VE3051C0 does not perform signal conversion or control processing. It provides carrier support and power distribution functions.
Q: What power input does the VE3051C0 require?
A: The carrier module accepts 30 VDC input power with a maximum current capacity of 8 A.
Field Installation Guidelines
- Install the VE3051C0 on the specified DeltaV mounting structure with correct mechanical alignment.
- Verify that the 30 VDC power source meets the carrier module input requirements before energizing the assembly.
- Maintain proper separation between DC power wiring and field signal cables to reduce electrical interference.
- Connect protective earth and cabinet grounding according to the control system installation standard.
- Inspect backplane contacts and module connectors before installation to prevent mechanical damage.
- Confirm environmental conditions remain within the specified temperature, humidity, vibration, and contamination limits.
