Overview
The CC-PDIL51 Digital Input Module from Honeywell accepts 24VDC signals and converts them into discrete inputs for Experion Series-C I/O systems. This module offers extensive internal diagnostics for data integrity and optional redundancy. It provides galvanic isolation and on-board excitation power, eliminating the need for external marshalling power. Moreover, users can select internal or external field power, and direct/reverse input indication simplifies monitoring and maintenance.
The Digital Input 24VDC accepts 24VDC signals as discrete inputs
Specification
| Parameter | Specification | ||
| Input/Output Model | CC-PDIL51-24Volt Digital Input | ||
| IOTA Models | CC-TDIL51 | Non Redundant | 9″ |
| CC-TDIL61 | Redundant | 12” | |
| Input Channels | 32 | ||
| Galvanic Isolation(any input terminal voltage referenced to common) | 1000 VAC RMS | ||
| lsolation Technique | Optical (in IOM) | ||
| DI Power Voltage Range | 18 to 30 VDC | ||
| ON Sense Voltage/Current | 13 VDC(min)or 3 mA(min) | ||
| OFF Sense Voltage/Current | 5VDC(max)or 1.2 mA(max) | ||
| Input Impedance | 4.2 KQ | ||
| Absolute Delay Across Input Filter and lsolation | 5ms±20% | ||
| Field Resistance for Guaranteed ON Condition | 300 Qmax @15VDC | ||
| Field Resistance for Guaranteed OFF Condition | 30 KQmin @30 VDC | ||
Manual/Datasheet PDF
CC-PDIL51 Honeywell Experion C300 Digital Input Model datasheet
