Overview
Specification
| Category | Specification |
|---|---|
| Range of Product | Modicon X80 |
| Product Type | Discrete Input Module |
| Number of Inputs | 64 |
| Input Type | Isolated, current sink (logic positive) |
| Input Voltage | 24 V DC positive |
| Input Current | 2.5 mA |
| Input Compatibility | 2-wire / 3-wire proximity sensors conforming to IEC 60947-5-2 |
| Sensor Power Supply | 19–30 V DC |
| Voltage State 1 Guaranteed | ≥ 11 V |
| Current State 1 Guaranteed | ≥ 2 mA |
| Voltage State 0 Guaranteed | ≤ 5 V |
| Current State 0 Guaranteed | ≤ 1.5 mA |
| Input Impedance | 9600 Ω |
| Insulation Resistance | > 10 MΩ at 500 V DC |
| Power Dissipation | ≤ 3.9 W |
| DC Typical Filtering Time | 4 ms |
| DC Maximum Filtering Time | 7 ms |
| Paralleling of Inputs | No |
| Typical Current Consumption | 140 mA at 3.3 V DC |
| MTBF Reliability | 696,320 hours |
| Protection Type | Reverse polarity protection, 0.5 A fast-blow fuse per channel group |
| Voltage Detection Threshold | <14 V DC sensor fault, >18 V DC sensor OK |
| Status LEDs | Green LED for module RUN, per-channel green for diagnostics, red LED for module I/O, red LED for module ERR |
| Product Weight | 0.112 kg |
FAQ
Q1: Is the BMXDDI6402K 100% genuine and factory-sealed?
A1: Yes, this module is fully original, factory-sealed, and brand new.
Q2: What is the typical shipping time?
A2: Orders ship within 3 days to 2 weeks depending on size, via DHL or similar carriers.
Q3: Can it handle both 2-wire and 3-wire sensors?
A3: Yes, the module supports both 2-wire and 3-wire proximity sensors.
Q4: Is there a return policy if there is a quality issue?
A4: Yes, we provide a 30-day return policy for any quality-related problems.
Q5: How is the module installed?
A5: It mounts on standard DIN rails and integrates seamlessly with Modicon Quantum X80 racks.
