Overview
Specification
| Feature | Specification |
|---|---|
| Module Type | Analog Output, Non-Isolated, High Level |
| Number of Outputs | 8 |
| Output Signals | 0–20 mA, 4–20 mA, ±10 V |
| Resolution | 15-bit + sign |
| Load Impedance | ≥500 Ω for current, ≥1000 Ω for voltage |
| Conversion Time | ≤1 ms |
| Maximum Output Current | 21 mA (0–20 mA / 4–20 mA) |
| Voltage Supply | Internal via rack |
| Status LEDs | 1 RUN (green), 1 ERR (red), 1 per channel (green) |
| Net Weight | 0.33 lb (0.15 kg) |
| Operating Temperature | 0–60 °C |
| Isolation Voltage | 1400 V DC between channels and bus |
FAQ
A: It is primarily designed for Modicon X80, but may work with compatible modular racks.
Q: What is the maximum load impedance for current output?
A: The module supports ≥500 Ω for both 0–20 mA and 4–20 mA signals.
Q: How quickly can the module process analog signals?
A: Conversion time is ≤1 ms, enabling real-time control feedback.
Q: Is the product new and in stock?
A: Yes, it is 100% original Schneider Electric. We have stock and ship within 3 days to 2 weeks depending on order size, using common carriers like DHL.
Q: Can I return the module if there is a quality issue?
A: Yes, we support returns within 30 days for quality concerns.
