Overview
Specification
| Category | Specification |
|---|---|
| Range of Product | Modicon X80 |
| Product Type | Analog Output Module |
| Electrical Connection | 20-way 1 connector |
| Analog Outputs | 4 channels |
| Output Signal Types | Current 0…20 mA, Current 4…20 mA, Voltage ±10 V |
| Output Resolution | 15 bits + sign |
| Output Level | High level |
| Conversion Time | ≤ 1 ms |
| Maximum Conversion Value | 0…21 mA (0…20 mA) / 0…21 mA (4…20 mA) / ±10.5 V (±10 V) |
| Isolation Voltage | 1400 V DC (channels ↔ ground, channels ↔ bus), 750 V DC (between channels) |
| Isolation Between Channels | Isolated |
| Measurement Error | ≤ 0.2 % full scale (0…60 °C), 0.1 % full scale (25 °C) |
| Temperature Drift | 45 ppm/°C (±10 V, 0…20 mA, 4…20 mA) |
| Crosstalk Attenuation | ≥ 80 dB |
| Common Mode Rejection | 100 dB |
| Detection Type | Open circuit (0…20 mA, 4…20 mA), Short circuit (±10 V) |
| Load Impedance | ≥ 1000 Ω (±10 V), ≤ 500 Ω (0…20 mA, 4…20 mA) |
| Supply | Internal power supply via rack |
| Fallback Mode | Configurable / Predefined |
| MTBF Reliability | 1,000,000 hours |
| Status Indicators | 1 Green LED (RUN), 1 Green LED per channel (diagnostic), 1 Red LED (ERR), 1 Red LED (I/O) |
| Operating Altitude | 0…2000 m (normal), 2000…5000 m (with derating factor) |
| Net Weight | 0.15 kg (0.33 lb US) |
| Dimensions (H x W x D) | 32 x 100 x 86 mm |
FAQ
Yes, all our products are 100% brand-new and original from Schneider Electric.Q2: Do you have stock available?
Yes, we hold ready stock. Orders ship within 3 days to 2 weeks, depending on quantity and logistics.
Q3: What shipping methods do you use?
We typically ship via DHL, FedEx, UPS, or other reliable international carriers.
Q4: What happens if the module has a quality issue?
We support returns within 30 days if any quality issues arise.
Q5: What are the supported output ranges of BMXAMO0410?
The module supports 0–20 mA, 4–20 mA, and ±10 V outputs, with isolated channels for high accuracy.
