Overview
The Honeywell 8C-TDIL01 is a coated Digital Input Sequence of Events (DI SOE) IOTA designed for the Experion C300 controller within the Series 8 platform. It provides 32 channels of 24V DC digital inputs, delivering high-speed event detection with a 1 millisecond sequence of events (SOE) resolution. The coated design protects the module against environmental contaminants, ensuring reliable operation in industrial applications.
This Series 8 IO function can detect and annunciate an open field wire. In addition, a seemingly valid PV from a channel diagnosed as having an open wire will provide a status of “invalid” (thus preventing incorrect control action).
Specification
| Attribute | Specification |
|---|---|
| Model Number | 8C-TDIL01 |
| Manufacturer | Honeywell |
| Series | Experion Series 8 |
| Module Type | Digital Input Sequence of Events (DI SOE) IOTA (Coated) |
| Input Channels | 32 |
| Input Voltage | 24V DC |
| SOE Resolution | 1 ms |
| Isolation | Optical |
| Coating | Yes (Conformal Coating Applied) |
| Mounting Type | DIN Rail |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Current Consumption | Approx. 190 mA @ 24V DC |
| Heat Dissipation | Approx. 4.22 W |
