Overview
Specification
| Parameter | Specification / Description |
|---|---|
| Model Number | 1X00781H01L |
| Product Type | Power Supply Module |
| Compatible System | Emerson Ovation DCS and related automation control environments |
| Input Voltage Range | 85–264 VAC or 90–375 VDC |
| Output Voltage | 24 VDC |
| Output Current | 10 A |
| Rated Power | ~240 W–360 W |
| Mounting | DIN‑rail mount |
| Efficiency | Up to ~86 % |
| Operating Temperature | -20 °C to 60 °C (-4 °F to 140 °F) |
| Protection Features | Overvoltage, undervoltage, overcurrent, short‑circuit protection |
| Enclosure Rating | IP20 |
| Dimensions | ~140 × 140 × 40 mm |
| Weight | ~0.68 kg |
| Warranty | Typically 12 months (new units) |
| Country of Origin | USA |
FAQ
A1: It supplies stable 24 VDC power to Ovation DCS controllers and associated modules in control cabinets.
Q2: Can this power supply operate worldwide?
A2: Yes, its wide AC/DC input range (85–264 VAC or 90–375 VDC) supports global power standards.
Q3: Does the module provide overcurrent protection?
A3: Yes, it includes protections for overvoltage, under‑voltage, overcurrent, and short circuits.
Q4: Is this supply easy to install?
A4: Yes, the DIN‑rail mount design allows quick installation in standard industrial cabinets.
Q5: What environments can the module withstand?
A5: It operates reliably between -20 °C and 60 °C, suitable for most industrial environments.
