Overview
Specification
| Parameter | Specification / Description |
|---|---|
| Model Number | 1X01046H01L |
| Module Type | Power Supply Module |
| Compatibility | Emerson Ovation DCS systems |
| Input Voltage | 120/240 VAC, 50/60 Hz |
| Output Voltage | 24 VDC nominal |
| Output Current | 5 A maximum |
| Power Rating | 120 W |
| Efficiency | >85% |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Storage Temperature | -20°C to 70°C (-4°F to 158°F) |
| Mounting Options | Rack mount or panel mount |
| Protection Features | Overvoltage, overcurrent, short-circuit protection |
| Response Time | Instantaneous for voltage fluctuation correction |
| Diagnostics & Monitoring | Voltage and current monitoring, status LEDs |
| Lifespan / Reliability | Designed for continuous industrial operation >10 years |
| Certifications | CE, UL recognized, compliant with Emerson quality standards |
FAQ
A1: Yes, it supports integration with most Ovation DCS systems, both current and legacy.
Q2: Can the module be replaced without shutting down the entire system?
A2: Yes, it features hot-swappable capability to reduce operational downtime.
Q3: What environmental conditions can this power supply handle?
A3: It operates reliably from 0°C to 60°C, with storage tolerance from -20°C to 70°C.
Q4: How is system monitoring achieved?
A4: The module provides voltage/current feedback and status LEDs for real-time diagnostics.
Q5: What support is available for installation or troubleshooting?
A5: Emerson provides technical guidance, installation support, and replacement parts.
