Overview
Specification
| Parameter | Specification / Description |
|---|---|
| Model Number | 1C31223G01 |
| Module Type | Relay Output Base |
| Compatible Modules | Emerson 1C31219G01 Relay Output Module |
| Mounting | Standard Ovation I/O rack |
| Electrical Connections | Screw terminal blocks with secure contact |
| Contact Rating Support | Up to 5 A @ 250 VAC / 30 VDC |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Storage Temperature | -40°C to 85°C (-40°F to 185°F) |
| Humidity Tolerance | 5% to 95% non-condensing |
| Material | High-strength industrial-grade polymer and metal contacts |
| Dimensions (W x H x D) | 25 mm x 120 mm x 100 mm (approx.) |
| Weight | 0.35 kg (0.77 lb) |
| Certifications | CE, UL recognized |
| Durability / MTBF | Long-term reliability; Mean Time Between Failures > 200,000 hours |
| Maintenance | Hot-swappable compatible for minimal system downtime |
FAQ
A1: It is compatible with Emerson 1C31219G01 and similar Ovation relay output modules.
Q2: Can this base handle high-temperature environments?
A2: Yes, it operates reliably between 0°C and 60°C.
Q3: Does it support hot-swappable modules?
A3: Yes, it is designed to allow module replacement with minimal downtime.
Q4: What is the material used for construction?
A4: High-strength industrial-grade polymer with durable metal contacts.
Q5: What certifications does the base have?
A5: CE certified and UL recognized for industrial safety compliance.
