Overview
Specification
| Specification | Details |
|---|---|
| Product Type | Discrete solid state I/O base DC |
| Range of Product | Modicon Momentum automation platform |
| Group of Channels | 2 groups of 8 outputs, 1 group of 16 inputs |
| Discrete Input Number | 16, conforming to IEC 1131-2 Type 1 |
| Discrete Input Logic | Positive |
| Discrete Input Voltage | 24 V DC |
| Discrete Output Number | 16 |
| Discrete Output Type | Solid state switch |
| Discrete Output Voltage | ≤ 30 V DC, 24 V DC |
| Discrete Output Logic | Positive |
| Protective Treatment | TC |
| Rated Supply Voltage [Us] | 24 V DC |
| Input Voltage Limits | -3…30 V |
| Voltage State 0 Guaranteed | -3…5 V |
| Voltage State 1 Guaranteed | 11…30 V |
| Current State 0 Guaranteed | ≤ 1.2 mA |
| Current State 1 Guaranteed | ≥ 2.5 mA |
| Input Resistance | 4 kΩ |
| Discrete Output Current | 4 A per group, 8 A per module, 0.5 A per point |
| Maximum Leakage Current | 1 mA at 24 V (output circuit) |
| Peak Output Current | 5 A |
| Maximum Voltage Drop | <0.5 V at 0.5 A (state 1 output circuit) |
| Fault Type | Overload on output |
| Response Time Output | <0.1 ms from state 0→1 and state 1→0 |
| Response Time Input | 2.2 ms from state 0→1, 3.3 ms from state 1→0 |
| Isolation Between Channels and Bus | 500 V AC |
| Power Dissipation | 6 W ≤ 8 W |
| Marking | CE |
FAQ
A1: Yes, the 170ADM35010 is 100% genuine and factory new.
Q2: How long does shipping take?
A2: We typically ship within 3–14 days, depending on order size and shipping method.
Q3: Which shipping methods are available?
A3: Common options include DHL, FedEx, and UPS.
Q4: Can I return the product if there’s a quality issue?
A4: Yes, we support returns within 30 days of delivery for defective units.
Q5: What are the physical dimensions and mounting options?
A5: The module measures 160 x 30 x 120 mm and supports DIN rail or chassis mounting.
