Overview
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | S9361DH-00 |
| Brand | Yokogawa |
| Product Type | Terminal Board Module |
| AC Voltage | 380-690 VAC (+/-10%), 3-phase |
| Frequency | 50/60 Hz |
| Nominal DC Voltage | 930 VDC |
| Control Circuit Voltage | 24 VDC (+/-15%) |
| Analog Input Signals | 0-10 V, 4-20 mA |
| Operating Temperature | -10 to +50 deg C |
| Temperature Derating | 2% per deg C above 40 deg C |
| Relative Humidity | Less than 95%, non-condensing |
| Country of Origin | Japan |
| Shipping Dimensions | 3.2 x 3.6 x 11.3 cm |
| Weight | 0.05 kg |
| HS Code | 8537101190 |
Electrical Ratings and Signal Ranges
The supplied data lists a three-phase AC voltage range of 380-690 VAC, with a tolerance of +/-10%. It also specifies a nominal DC voltage of 930 VDC and a separate 24 VDC control circuit. These values describe different electrical ratings, so users should check their functions before selecting or connecting the equipment.
In addition, the listed analog input ranges are 0-10 V and 4-20 mA. These ranges represent voltage and current signals, respectively. However, the available information does not specify the number of input channels, terminal assignments or signal isolation.
Operating Environment
The stated operating temperature range extends from -10 to +50 deg C. Above 40 deg C, the supplied data specifies a derating rate of 2% per deg C. Therefore, users should check the applicable load or output rating when planning operation at higher temperatures.
The humidity limit is less than 95% relative humidity without condensation. This condition helps define the environmental limits for equipment selection and installation.
Frequently Asked Questions
Q: What is the Yokogawa S9361DH-00?
A: The S9361DH-00 is a Yokogawa terminal board module. Its exact terminal functions and associated equipment require confirmation before replacement or integration.
Q: Which analog signal ranges appear in the specifications?
A: The supplied data lists 0-10 V and 4-20 mA analog input signals. However, it does not confirm the channel count or terminal layout.
Q: What should users check before replacing this module?
A: First, verify the complete S9361DH-00 model number and terminal arrangement. Next, compare the electrical ratings and signal requirements with the existing equipment. This helps avoid selecting a module with different connection or operating requirements.
