Overview
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | NFBU200-S10 S1 |
| Brand | Yokogawa |
| Product Type | 19 Inch Rack Base Module |
| Origin | Japan |
| Weight | 1.2 kg |
| Dimensions | 6 x 25.8 x 24.3 cm |
| Power Consumption | Passive base module, no direct power consumption specified |
| Rack Type | 19 inch rack-mounted |
| Mountable I/O Modules | Maximum 8 modules |
| Mountable Power Supply Modules | Maximum 2 modules |
| Mounting Style | Standard type, rack installation |
| DIN Mount Compatibility | Supported |
| Function | Base connection structure for I/O and power supply module installation |
| Tariff Code | 8537101190 |
Yokogawa Rack Integration and I/O Density Configuration
The NFBU200-S10 S1 provides the mechanical and electrical mounting structure for Yokogawa control system modules. It supports a maximum configuration of 8 I/O modules and 2 power supply modules within a 19 inch rack arrangement.
Furthermore, the base module maintains the physical alignment of installed modules and provides the internal connection path between mounted hardware components. The S1 style identifies the standard rack-mounted configuration without additional application-specific modifications.
The module supports Yokogawa system expansion through I/O density scaling by allowing multiple functional modules to be installed on a common rack assembly. Therefore, engineers can configure the rack layout according to required signal processing and power distribution requirements.
Frequently Asked Questions
Q: How many I/O modules can the Yokogawa NFBU200-S10 S1 support?
A: The NFBU200-S10 S1 supports a maximum of 8 mountable I/O modules.
Q: Can the NFBU200-S10 S1 install power supply modules?
A: Yes. The base module supports up to 2 mountable power supply modules within the rack configuration.
Q: Does the NFBU200-S10 S1 require separate operating power?
A: The NFBU200-S10 S1 functions as a passive rack base structure. The provided data does not specify independent power consumption.
Field Installation Guidelines
- Install the NFBU200-S10 S1 on a compatible 19 inch rack structure using the specified mechanical mounting points.
- Verify rack alignment before inserting I/O and power supply modules to prevent connector damage.
- Keep signal wiring separated from high-current power cables to reduce electrical interference.
- Connect cabinet grounding according to the control system installation requirements.
- Confirm module seating and connector engagement after installation before system startup.
- Maintain sufficient cabinet clearance for module insertion, inspection, and maintenance access.
