| Parameter | Specification |
|---|---|
| Model | EC401-10 S2 |
| Spare Model | EC401-10 |
| Brand | Yokogawa |
| Product Type | ESB Bus Coupler Module |
| Function | Bus Coupling |
| Origin | Singapore |
| Weight | 0.3 kg |
| Dimensions | 15.2 cm x 15.2 cm x 5.1 cm |
ESB Bus Coupling and Communication
The EC401-10 S2 serves as a bus coupling component within Yokogawa control system hardware. Its assigned function is to support communication connectivity between compatible system modules through the ESB bus architecture.
During system configuration, verify the module’s compatibility with the installed control system hardware and communication architecture. The available specifications do not identify supported communication rates, electrical interface limits, or bus termination requirements.
Frequently Asked Questions (FAQ)
Q: What is the primary function of the Yokogawa EC401-10 S2?
A: It is an ESB Bus Coupler Module designed for bus coupling within Yokogawa control system hardware.
Q: Is the EC401-10 S2 interchangeable with other ESB modules?
A: Interchangeability depends on the system configuration, hardware revision, and manufacturer compatibility requirements. Verify the applicable system documentation before replacement.
Q: What are the physical dimensions and weight of the EC401-10 S2?
A: The estimated shipping dimensions are 15.2 cm x 15.2 cm x 5.1 cm, and the listed weight is 0.3 kg.
Field Installation Guidelines
- Confirm the module designation and hardware compatibility against the applicable Yokogawa system documentation.
- Isolate the relevant equipment power supply before removing or installing the module.
- Inspect the module connector and mounting interface for physical damage or contamination.
- Align the module with the designated mounting position and secure the connection according to the system installation procedure.
- Maintain separation between communication wiring and power conductors where applicable.
- Verify bus connections and system status after installation.
- Do not assume hot-swap capability or specific electrical operating limits without confirmation from the manufacturer’s documentation.
