Overview
Configured for actuator command execution and electrical signal conversion in Woodward 8200 control platforms, the Woodward 8200-1205 (8200 Digital Driver Board) provides direct physical and electrical execution between control logic and field actuator circuits.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | 8200-1205 |
| Brand | Woodward |
| Origin | USA |
| Product Type | Digital Driver Boards |
| Function | Actuator driver and control signal interface module |
| Control Application | Turbine governor and prime mover control systems |
| Power Supply | Typically 18 to 32 VDC input range, nominal 24 VDC |
| Signal Processing | Digital signal processing with analog interface conversion |
| Output Interface | Actuator command output interface |
| Mounting Type | Industrial control panel or rack mounting configuration |
| Dimensions | Specific dimensions depend on hardware configuration |
| Weight | Specific weight depends on enclosure and assembly configuration |
| Operating Temp | Industrial operating range; exact value depends on installation configuration |
| Power Consumption | Depends on connected actuator load and system configuration |
Actuator Loop Feedback and Governor Control Characteristics
The Woodward 8200 series supports actuator loop control functions by processing command signals from governor or control logic modules. The 8200-1205 interfaces with actuator circuits and maintains output regulation through feedback signal monitoring.
For governor applications, the module manages actuator response behavior by controlling electrical output conversion and maintaining closed-loop execution. In addition, actuator loop feedback response characteristics depend on the connected servo system, actuator type, and configured control parameters.
The module design supports industrial environments where signal integrity, electrical noise resistance, and stable actuator positioning are required. Furthermore, installation practices must maintain proper shielding and grounding to reduce interference in low-level control signals.
Frequently Asked Questions
Q: Can the Woodward 8200-1205 operate as a standalone controller?
A: No. The module functions as a control interface component and requires integration with a compatible Woodward control system that provides command logic.
Q: Does the 8200-1205 support actuator feedback monitoring?
A: The module supports actuator control loop functions when connected to compatible feedback devices and configured control hardware.
Q: Are firmware functions interchangeable between different 8200 series variants?
A: Firmware compatibility depends on the exact hardware revision and application configuration. The installed firmware must match the specified module revision.
Field Installation Guidelines
- Install the module according to the approved Woodward system wiring documentation and equipment drawings.
- Verify the power supply polarity before connecting the 24 VDC control circuit.
- Use shielded cables for actuator command and feedback wiring where required by the control system design.
- Connect cable shields according to the site grounding standard to minimize electrical noise coupling.
- Separate actuator wiring from high-voltage power cables to reduce electromagnetic interference.
- Confirm connector seating and terminal tightness before system commissioning.
- Verify actuator feedback signals and output response during functional testing.
