Overview
This module efficiently manages breaker commands, trip logic, and interlocking signals, making it an essential element for protection and control systems across substations and power plants.
Specification
| Parameter | Description |
|---|---|
| Model | GE Fanuc Multilin UR-6EV |
| Module Type | Control Module |
| Manufacturer | GE (General Electric) / Multilin |
| Functionality | Digital control, breaker operation, logic execution |
| Digital Inputs | 16 optically isolated inputs |
| Digital Outputs | 8 Form-A or Form-C relay outputs |
| Input Voltage Range | 24–250 V DC |
| Output Contact Rating | 250 V AC / 30 V DC at 5 A resistive |
| Isolation Voltage | 2000 Vrms between channels and logic |
| Logic Execution Speed | <5 ms typical |
| Communication Interface | UR Series backplane connection |
| Operating Temperature | –40°C to +70°C (–40°F to +158°F) |
| Humidity | 5%–95% non-condensing |
| Mounting Type | Plug-in module, hot-swappable |
| Diagnostics | Continuous self-test and event logging |
| Certifications | CE, UL, CSA, IEC approved |
| Dimensions | Approx. 150 mm × 60 mm × 20 mm |
| Weight | Approx. 0.25 kg (0.55 lbs) |
FAQ
Yes, it integrates seamlessly with all UR Series Universal Relay chassis models.
Q2: What is the main role of the UR-6EV in a protection system?
It manages control logic, breaker commands, and tripping operations for system protection and automation.
Q3: Can this module be replaced while the system is running?
Yes. The UR-6EV supports hot-swapping, allowing safe replacement without system shutdown.
Q4: Does the module support event recording?
Absolutely. It continuously logs control events and fault signals for diagnostic review.
