Overview
Specification
| Parameter | Description |
|---|---|
| Model | GE Fanuc Multilin UR-6AV |
| Module Type | Digital Input/Output (I/O) Module |
| Manufacturer | GE (General Electric) / Multilin |
| Inputs | 16 optically isolated digital inputs |
| Outputs | 8 Form-A or Form-C relay outputs |
| Input Voltage Range | 24 to 250 V DC (configurable) |
| Input Threshold | Logic ON above 19 V DC |
| Output Contact Rating | 30 V DC / 250 V AC at 5 A resistive |
| Isolation Voltage | 2000 Vrms between I/O and logic |
| Response Time | < 4 ms typical for input transitions |
| Communication Interface | UR Series backplane bus |
| Module Power Supply | Provided from UR base chassis |
| Operating Temperature | –40°C to +70°C (–40°F to +158°F) |
| Humidity | 5% to 95% non-condensing |
| Mounting Type | Plug-in card, hot-swappable |
| Protection Features | Overvoltage suppression and input filtering |
| Certifications | CE, UL, CSA, IEC compliant |
| Dimensions | Approx. 150 mm x 60 mm x 20 mm |
| Weight | Approx. 0.25 kg (0.55 lbs) |
FAQ
Yes, it is fully compatible with all GE Multilin UR Series Universal Relay mainframes.
Q2: Can the UR-6AV handle both AC and DC signals?
The inputs are designed primarily for DC operation, while outputs can control AC or DC loads within rated limits.
Q3: Does it support remote monitoring via communication protocols?
Yes. When installed in a UR chassis, it supports remote configuration and monitoring through Modbus, DNP3, or IEC protocols.
Q4: What is the main benefit of using this module?
It enhances digital control flexibility, enabling efficient signal management and system scalability within protection and automation networks.
