TC-RPSCA2 Honeywell Power System

Overview

The Honeywell TC-RPSCA2, also cataloged as the TC-RPSCA2 Redundant Power Supply Chassis Adapter, operates as a dedicated hardware component for redundant power distribution between power supply modules and Series-A chassis backplanes within Honeywell Experion PKS systems. The TK-RPSCA2 variant provides the same function with conformal coating protection.

Hardware Specifications

Channel-to-Channel Isolation and DCS Power Interface

The TC-RPSCA2 interfaces redundant Honeywell power modules with Series-A chassis backplane power rails. It transfers power through dedicated cable connections and maintains separation between redundant supply paths.

Furthermore, the adapter supports Honeywell DCS hardware architectures where controlled power distribution and channel-to-channel isolation requirements apply. The module operates as a passive power interface and does not process field signals, HART communication, FOUNDATION Fieldbus, or Profibus PA data streams.

The adapter configuration allows two independent power sources to feed the chassis power network. Therefore, the system can maintain chassis operation when one redundant power supply path becomes unavailable.

Frequently Asked Questions

Q: Does the TC-RPSCA2 occupy a standard I/O module slot?
A: No. The adapter mounts on the far-left side of the Series-A chassis and does not consume an I/O slot position.

Q: Which power supply modules connect to the TC-RPSCA2?
A: The adapter connects Honeywell TC-RPCXX1 AC redundant power supplies and TC-RPDXX1 DC redundant power supplies through dedicated redundant power cables.

Q: Does the TC-RPSCA2 require firmware configuration or software loading?
A: No. The module functions as a hardware power interface adapter and does not require firmware installation.

Field Installation Guidelines

1. Install the TC-RPSCA2 on the designated left-side chassis mounting position before connecting redundant power cables.
2. Verify that the chassis type matches the supported Series-A configurations before mechanical installation.
3. Connect TC-RPSC04 redundant power cables according to the chassis power connection requirements.
4. Route power cables separately from high-voltage switching lines and high-frequency noise sources to reduce electrical interference.
5. Confirm connector engagement and mechanical locking before energizing the redundant power supply system.
6. Apply proper cabinet grounding practices according to the Honeywell chassis installation documentation.
