Overview
Specification
| Parameter | Specification |
|---|---|
| Part Number | 3ADT309600R0012 |
| Product Type | Control Board |
| Series | SDCS-CON-2B |
| Function | Central control and communication unit for ABB drives |
| Nominal Voltage | 24 VDC |
| Processor Type | Embedded controller for real-time operation |
| Communication Ports | Analog I/O, digital I/O, serial interfaces |
| Protection Features | Overvoltage, short-circuit, temperature monitoring |
| Operating Temperature | 0°C to +55°C |
| Mounting Method | Plug-in board |
| Dimensions | Compact modular size |
| Compatible Systems | ABB DCS500, DCS600 series drives |
| Certifications | CE, UL, and RoHS compliant |
FAQ
Q1: What is the main purpose of the ABB SDCS-CON-2B control board?
A1: It controls communication and system logic between the drive converter and external interfaces.
Q2: Which ABB drives are compatible with this module?
A2: It is fully compatible with ABB DCS500 and DCS600 DC drive systems.
Q3: What voltage does the board operate on?
A3: It operates on a nominal 24 VDC power supply.
Q4: Does it include built-in protection features?
A4: Yes, it offers overvoltage, short-circuit, and temperature protection.
Q5: In what industries is this board commonly used?
A5: It is widely applied in metals, marine, paper processing, and other heavy-duty automation industries.
