Overview
This CPU module integrates naturally with the Yokogawa CENTUM VP system, allowing teams to expand their architecture without major engineering changes. Therefore, users can upgrade legacy nodes or deploy new units while retaining full compatibility with existing I/O networks and communication layers.
Specification
| Parameter | Description |
|---|---|
| CPU Type | High-performance CPU module for CENTUM VP FCS |
| Processor Speed | Deterministic high-speed processing for complex control tasks |
| Program Memory | Dedicated memory for control logic and application strategies |
| Data Memory | Runtime memory for system variables, buffers, and trend data |
| System Platform | Yokogawa CENTUM VP Field Control Station (FCS) |
| Communication Interface | High-reliability FCS control bus |
| Redundancy Support | Supports optional redundant FCS configurations |
| Diagnostics | Continuous internal self-diagnostic and fault monitoring |
| Power Requirement | Standard FCS power supply; low-consumption module design |
| Operating Temperature | 0°C to 55°C suitable for control-room environments |
| Storage Temperature | -20°C to 70°C compliant with long-term storage demands |
| Humidity Range | 5% to 95% RH non-condensing |
| EMC Protection | Industrial electromagnetic immunity for stable operation |
| Vibration Rating | Cabinet-mounted vibration tolerance for industrial sites |
| Cooling Method | Passive cooling without internal mechanical components |
| Installation Method | Plug-in module for FCS system backplane slots |
| Typical Applications | Oil & gas, refining, petrochemical, power generation, and utilities |
| Compliance | Meets CE and industrial automation safety standards |
FAQ
A1: It works with Yokogawa CENTUM VP and fits directly into FCS control stations.
Q2: Does the module handle heavy real-time workloads?
A2: Yes, its fast execution cycle and stable multitasking engine support demanding process strategies.
Q3: Can it replace older Yokogawa CPU models?
A3: In most cases, yes. The module aligns with standard FCS layouts, making retrofit projects straightforward.
Q4: What environments suit this CPU module?
A4: It operates reliably in chemical plants, refineries, power stations, and other heavy-industry environments.
Q5: How does the module support maintenance?
A5: It includes diagnostic features and follows a quick-swap design, allowing fast replacement during planned outages.
