Overview
Specification
| Parameter | Specification |
|---|---|
| Model | NFCP501-S05 S2 |
| Module Type | CPU Module |
| Compatible System | CENTUM VP |
| Power Supply | 24 V DC ±10% |
| Power Consumption | 25 W typical |
| Logic Execution Speed | High-speed processing capable of sub-millisecond cycle execution |
| Main Memory | 64 MB RAM for program and data storage |
| Non-volatile Memory | 16 MB flash memory for firmware and configuration storage |
| Communication Interfaces | Redundant ISBus, Ethernet (10/100 Mbps), RS-232/RS-422 serial links |
| Number of I/O Channels Supported | Up to 512 digital/analog points depending on system configuration |
| Redundancy Capability | Supports dual CPU redundancy for critical process control |
| Operating Temperature Range | 0°C to 55°C |
| Storage Temperature Range | -20°C to 70°C |
| Relative Humidity | 10–90% RH, non-condensing |
| Mounting | Rack-mountable |
| Safety Standards | CE, UL, IEC 61131, EMC industrial compliance |
| System Integration | Compatible with Yokogawa CENTUM VP R3/R5 and FCS systems |
| LED Indicators | Status, RUN, ERROR, COMM, POWER |
| Watchdog Function | Hardware and software watchdog for fault detection |
| Firmware Update | Online and offline update support |
| Diagnostics | Self-diagnostics, system logging, and remote monitoring |
| Mean Time Between Failures (MTBF) | >100,000 hours |
FAQ
A1: It integrates seamlessly into CENTUM VP systems, supporting modular and scalable upgrades.
Q2: Can it operate reliably in harsh industrial environments?
A2: Yes, the CPU module features a robust industrial design for continuous operation.
Q3: Does it support real-time process monitoring?
A3: Absolutely, it executes high-speed logic and data processing for real-time control.
Q4: What kind of communication interfaces are included?
A4: It offers ISBus, Ethernet, and serial links for redundant and reliable connectivity.
Q5: Is system redundancy supported?
A5: Yes, the module supports redundancy for critical process reliability.
Q6: What temperature range can it operate in?
A6: The module functions safely in 0°C to 55°C for industrial environments.
