ISI202 Bachmann Positioning Module

Hardware Specifications

Encoder and Position Processing

The ISI202 accepts two encoder input channels for incremental and SSI position feedback. It processes encoder counts through a full 32 bit counter, allowing the controller to retain position information for motion-related functions.

Furthermore, four fast digital inputs accept initiator and trigger signals. These inputs can initiate position measurement or position storage according to the application logic.

The module also provides two 14 bit analog outputs. Therefore, the controller can use processed positioning information for analog signal generation where the application requires it.

Virtual values support functions such as zero pulse and speed calculation. In addition, SYNC and PreSYNC provide synchronization mechanisms for coordinated position processing within the control system.

For installation, encoder signal wiring should remain separated from high-current switching conductors and motor power cables. Use suitable shielded signal cables for encoder circuits and terminate shields according to the cabinet grounding concept.

Frequently Asked Questions (FAQ)

Q: What encoder types does the ISI202 support?
A: The module provides two input channels for incremental and SSI encoders.

Q: Can the module initiate position measurement from an external signal?
A: Yes. Four fast digital inputs support initiator and trigger signals, which can initiate position measurement or position storage.

Q: What synchronization functions are available?
A: The ISI202 supports SYNC and PreSYNC synchronization for coordinated position processing.

Field Installation Guidelines

1. Install the module in the designated Bachmann control-system mounting position and verify correct mechanical engagement before energizing the system.
2. Connect incremental or SSI encoder wiring to the assigned encoder input channels according to the application wiring documentation.
3. Route encoder and trigger wiring separately from contactor, relay, motor, and other high-current conductors to reduce electrical interference.
4. Use shielded signal cables where required by the installation environment. Connect cable shields according to the plant grounding and EMC design.
5. Connect initiator and trigger signals to the four fast digital inputs using the specified field wiring arrangement.
6. Route the two analog output circuits separately from high-frequency switching conductors where practical.
7. Verify encoder direction, counter operation, trigger response, position storage, and synchronization behavior during commissioning.
8. Confirm that the actual cabinet operating temperature and module power requirements comply with the applicable Bachmann system documentation before installation.
