Overview
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | MPC293 |
| Brand | Bachmann |
| Product Series | MPC200 Series |
| Product Type | CPU Processor Module |
| System | Bachmann M1 Automation System |
| Processor Architecture | Embedded Intel Celeron / Pentium III class |
| Clock Speed | Up to 933 MHz, depending on variant |
| Mass Storage | CompactFlash (CF) card support |
| Real-Time Operation | Deterministic control processing |
| Communication | M1 system communication and supported industrial networks |
| Memory / Storage | CompactFlash-supported mass storage |
| Mounting | Modular control cabinet installation |
Industrial Control and Backplane Communication
The MPC293 processes PLC application tasks and exchanges data with the M1 system through its modular system architecture. Its processor platform supports deterministic execution for control logic, communication handling, and system-level data processing.
Furthermore, the MPC200 architecture supports expansion through Bachmann I/O modules. The actual communication interfaces, network protocols, and available system resources depend on the installed hardware configuration and firmware.
CompactFlash support provides removable mass-storage capability for system data and application-related files. Therefore, storage configuration should match the controller hardware and software compatibility requirements.
Frequently Asked Questions (FAQ)
Q: Does the MPC293 support CompactFlash storage?
A: Yes. The supplied specifications identify CompactFlash (CF) card support for mass storage.
Q: What processor architecture does the MPC293 use?
A: The supplied data identifies an embedded Intel Celeron / Pentium III class processor architecture, with variants supporting clock speeds up to 933 MHz.
Q: Can the MPC293 operate with Bachmann M1 I/O modules?
A: Yes. The MPC293 belongs to the MPC200 family for the Bachmann M1 Automation System and supports expansion through compatible Bachmann I/O modules.
Field Installation Guidelines
- Install the module on the designated Bachmann M1 system mounting structure and secure all mechanical connections.
- Verify backplane and module alignment before applying system power.
- Route power and signal wiring separately where practical to reduce electrical interference.
- Maintain appropriate separation between communication cables and high-current switching conductors.
- Connect cable shields according to the cabinet grounding and EMC design used for the installation.
- Confirm the installed CompactFlash device and firmware configuration before commissioning.
- Do not remove or insert removable storage during operations unless the installed hardware and software explicitly support that procedure.
- Verify controller configuration, communication parameters, and application firmware before placing the system into service.
