Overview
In addition, the IS220PDIOH1B features fast switching capabilities and secure terminal connections, enabling engineers to implement efficient control strategies. Its modular design simplifies diagnostics and maintenance, making it ideal for critical process applications where reliability is essential.
Specification
| Parameter | Specification / Detail |
|---|---|
| Part Number / Model | IS220PDIOH1B |
| Module Type | Discrete Input / Output (I/O) Module / I/O Pack |
| System Compatibility | GE Mark VIe (Mark VIe / Mark VIeS turbine-control systems) |
| Discrete Input Channels | 16 isolated digital input channels |
| Discrete Output Channels | 16 isolated digital output channels |
| Input Voltage (nominal) | 24 V DC typical |
| Input Voltage Range (ON) | 20–30 V DC |
| Input Voltage Range (OFF) | 0–5 V DC |
| Output Voltage (nominal) | 24 V DC typical |
| Output State Voltage Range | 20–30 V DC when output ON, 0–5 V DC when OFF |
| Output Type | Relay or transistor outputs (configurable as discrete DO) |
| Isolation | Channel-to-channel and channel-to-ground isolation |
| Communication Interface | Dual redundant Ethernet ports for I/O network connectivity |
| Power Supply / Operating Voltage Range | Nominal 24 V DC; typical module draws from 24 V DC supply |
| Operating Temperature Range | –40 °C to +70 °C |
| Humidity / Environment | 5 – 95% RH, non-condensing |
| Mounting / Connection | Plug-in module into I/O rack/backplane; field wiring via terminal board or connector |
| Diagnostic & Monitoring Features | Module supports diagnostics, status monitoring, and redundant I/O configuration |
| Typical Application Areas | Turbine control systems, industrial automation, process control, discrete device monitoring and actuation |
FAQ
A1: It integrates with GE Fanuc Mark VIe control systems and standard field terminal boards.
Q2: How many input and output channels does this module provide?
A2: The module provides 16 discrete input and 16 discrete output channels for flexible digital control.
Q3: What is the maximum current per output channel?
A3: Each output channel supports up to 0.5 A, ensuring reliable operation for connected devices.
Q4: Can this module handle harsh industrial environments?
A4: Yes, it operates from –40 °C to +70 °C with 5–95% non-condensing humidity.
Q5: How does it support system diagnostics and maintenance?
A5: The modular architecture and clear terminal layout allow easy diagnostics and maintenance.
