Overview
The GE IS200AEPAH1BHC (IS215WEPAH2AB) is identified in the supplied information as a printed circuit board for turbine control applications. The listed configuration includes 16 differential or single-ended input channels, 8 single-ended output channels, 12-bit resolution, and a CAN bus interface. These details provide an initial reference for checking the board’s signal configuration and electrical requirements before procurement or replacement.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | IS200AEPAH1BHC |
| Alternate Model Reference | IS215WEPAH2AB |
| Brand | GE |
| Product Type | Printed Circuit Board (PCB) |
| Operating Voltage | 5 VDC |
| Power Supply Rating | 125 VDC |
| Input Channels | 16, differential or single-ended |
| Output Channels | 8, single-ended |
| Resolution | 12-bit |
| Sampling Rate | 200 kHz |
| Communication Interface | CAN bus |
| Data Transfer Rate | 1 Mbps |
| Maximum Power Consumption | 4 W |
| Operating Temperature | -40 to 70 deg C |
| Storage Temperature | -40 to 70 deg C |
| Humidity Range | 5-95% RH, non-condensing |
| Software Frame Rates | 10 ms, 20 ms, and 40 ms |
Signal Configuration and Data Handling
The listed input configuration supports either differential or single-ended signals. These connection types use different signal reference arrangements, so the required input mode and terminal assignment should be confirmed before wiring. The eight single-ended outputs provide a separate output channel configuration; the available information does not specify the supported signal ranges.
The stated 12-bit resolution defines the nominal number of discrete digital levels available for a converted signal. The 200 kHz sampling rate and selectable software frame rates of 10 ms, 20 ms, and 40 ms describe different aspects of data acquisition and processing. Their relationship to the board’s actual operating mode requires confirmation against the applicable technical documentation.
Communication and Electrical Requirements
The CAN bus interface is listed with a data transfer rate of 1 Mbps. Confirm the required bus configuration and communication settings before integrating the board into an existing control system.
The supplied specifications list both a 5 VDC operating voltage and a 125 VDC power supply rating. These values may refer to different electrical functions, but their exact meanings are not established by the available information. Verify the board’s power connections and supply requirements before energizing it.
Frequently Asked Questions
Q: What is the difference between IS200AEPAH1BHC and IS215WEPAH2AB?
A: The supplied information lists both identifiers together. It does not establish whether they represent interchangeable boards, a replacement relationship, or different assembly configurations. Confirm the complete part number and hardware revision before ordering a replacement.
Q: Can the board accept both differential and single-ended inputs?
A: The supplied specifications list 16 input channels that support differential or single-ended configurations. The exact wiring arrangement, supported signal ranges, and channel configuration requirements still need confirmation.
Q: What power supply does the board require?
A: The listed values are 5 VDC operating voltage and a 125 VDC power supply rating. Their respective functions are unclear, so do not select a supply based on either value alone without confirming the electrical requirements for this exact model.
