Overview
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | FS212/N |
| Base Model | FS212 |
| Brand | Bachmann |
| Product Type | FASTBUS Module |
| Function | FASTBUS slave module |
| Fiber Interfaces | 1 or 2 FO interfaces |
| Power Supply | Integrated |
| Maximum Distributed Substations | Up to 15 |
| POF Cable Distance | Up to 40 m between stations |
| HCS Cable Distance | Up to 150 m between stations |
| Special HCS Cable Distance | Up to 180 m between stations |
| Status Indication | RUN / ERR |
| Fiber Type Indication | Supported |
| Origin | Austria |
| Place of Shipment | Xiamen, China |
| Weight | 0.3 kg |
| Estimated Shipping Size | 5.5 cm x 6 cm x 12 cm |
FASTBUS Fiber Communication Characteristics
The FS212/N functions as a FASTBUS slave node and provides one or two fiber-optic interfaces. The optical interface supports distributed communication while reducing dependence on conventional electrical signal cabling.
Furthermore, the module supports different fiber cable types with defined station-to-station distances. POF cables support distances up to 40 m, while HCS cables support up to 150 m. Special HCS cables extend the stated distance to 180 m.
The integrated power supply reduces the number of separate power hardware elements required at the FASTBUS slave location. The module also provides RUN and ERR status indication, together with fiber-type indication for operational identification.
Frequently Asked Questions (FAQ)
Q: How many distributed substations can the FS212/N support?
A: The supplied specification states support for up to 15 distributed substations.
Q: What fiber cable distances does the FS212/N support?
A: The stated distances are up to 40 m for POF, 150 m for HCS, and 180 m for special HCS cables between stations.
Q: Does the FS212/N include a power supply?
A: Yes. The supplied data identifies the FS212/N as a FASTBUS slave module with an integrated power supply.
Field Installation Guidelines
- Install the FS212/N in the designated Bachmann system mounting location and secure the module mechanically before connecting field interfaces.
- Route fiber-optic cables separately from high-voltage power conductors and high-current switching cables where practical.
- Select POF, HCS, or special HCS cabling according to the required station-to-station distance.
- Keep fiber connectors clean and protected from dust during installation.
- Verify the fiber interface type before commissioning the communication link.
- Check the RUN and ERR indicators after power application to confirm the module operating state.
- Maintain clear separation between communication wiring and sources of electromagnetic interference.
- Do not assume operating temperature or power-consumption limits beyond the manufacturer data provided for this module.
- Confirm the complete FASTBUS topology and station count before energizing the distributed network.
