Overview
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | VE4022 |
| Brand | Emerson |
| Product Type | Profibus DP Interface Card |
| Origin | USA |
| Weight | 0.24 kg |
| Dimensions | 4.3 x 12.5 x 13.5 cm estimated shipping size |
| Operating Temp | -40 deg C to +70 deg C |
| Power Consumption | 12 VDC at 600 mA local bus power |
| Communication Interface | Profibus DP |
| Tariff Code | 8537101190 |
| Shipment Location | Xiamen, China |
| Module Function | Profibus network interface and field communication processing |
FOUNDATION Fieldbus / Profibus Connectivity and Channel Isolation
The Emerson VE4022 integrates Profibus DP communication capability within Emerson process control architectures. Therefore, the module handles cyclic data transfer between connected Profibus devices and the DeltaV control environment.
The interface card uses local bus power supplied at 12 VDC with a 600 mA current requirement. Additionally, the module design supports industrial communication installation where signal integrity depends on proper grounding, cable shielding, and network topology control.
The VE4022 follows Emerson process control hardware practices for digital communication modules. Moreover, field wiring separation and communication cable management help reduce electromagnetic interference during operation.
Frequently Asked Questions
Q: What communication protocol does the Emerson VE4022 support?
A: The VE4022 supports Profibus DP communication for data exchange between Emerson control hardware and compatible Profibus field devices.
Q: What local bus power does the VE4022 require?
A: The module requires 12 VDC local bus power with a current consumption of 600 mA.
Q: What environmental conditions are specified for VE4022 operation?
A: The module supports an ambient temperature range from -40 deg C to +70 deg C, with specified shock and vibration resistance values.
Field Installation Guidelines
Install the Emerson VE4022 in the designated DeltaV hardware carrier according to Emerson system installation procedures.
Verify that the local bus power supply provides 12 VDC before module insertion. Check connector alignment and ensure that the module seats correctly within the carrier.
Use shielded Profibus cables and maintain proper cable routing separation from high-voltage power wiring. Connect cable shields according to the plant grounding standard to reduce communication interference.
Inspect the Profibus network termination configuration before commissioning. Confirm that connected devices use compatible Profibus DP settings and that communication parameters match the control system configuration.
Avoid mechanical stress on connectors and maintain environmental conditions within the specified operating range.
