Overview
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | VE4050S2K1C0 |
| Brand | Emerson |
| Product Type | Extender Cable |
| Product Parameters | 8-Wide I/O Interface Carrier with Carrier Shield Bar |
| Origin | USA |
| Weight | 0.2 kg |
| Dimensions | 4.2 cm x 12.5 cm x 10.5 cm |
| Operating Temp | -40 to 70 deg C |
| Storage Temp | -40 to 85 deg C |
| Relative Humidity | 5 to 95%, non-condensing |
| Power Consumption | Passive cable assembly, no external power consumption |
Process Control Interface and Carrier Connection Features
The Emerson VE4050S2K1C0 supports physical extension between DeltaV I/O carrier components. Therefore, the cable assembly maintains the required electrical connection path for carrier-based I/O expansion structures.
The component is designed for use with Emerson DeltaV modular hardware arrangements where I/O carriers require extended connection routing. In addition, the carrier shield bar supports cable shielding practices to reduce unwanted electrical interference in industrial control environments.
The Emerson DeltaV platform uses modular I/O architectures for process signal handling. However, the VE4050S2K1C0 itself functions as a passive interconnection component and does not perform signal processing, protocol conversion, or channel isolation.
Frequently Asked Questions
Q: Does the VE4050S2K1C0 perform signal conditioning or data conversion?
A: No. The VE4050S2K1C0 is an extender cable assembly and only provides physical electrical extension between compatible carrier components.
Q: Can the VE4050S2K1C0 operate under industrial temperature conditions?
A: Yes. The specified operating temperature range is -40 to 70 deg C, with storage capability from -40 to 85 deg C.
Q: Does the VE4050S2K1C0 require an external power supply?
A: No. The extender cable is a passive hardware component and does not require an external power connection.
Field Installation Guidelines
- Install the VE4050S2K1C0 only with compatible Emerson DeltaV carrier assemblies.
- Verify connector alignment before mechanical engagement to prevent contact damage.
- Maintain proper cable routing to avoid excessive bending, pulling force, or mechanical stress.
- Connect shielding components according to the system grounding design to reduce electrical noise coupling.
- Separate the cable path from high-current power conductors where possible to minimize electromagnetic interference.
- Confirm environmental conditions remain within the specified operating temperature and humidity limits before commissioning.
