Overview
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | VE4006P2 |
| Spare Model | KJ3241X1-BA1 |
| Product Type | Serial Interface Card |
| Brand | Emerson |
| Origin | USA |
| Weight | 0.18 kg |
| Dimensions | 5.1 cm x 12.7 cm x 12.7 cm |
| Operating Temp | -40 deg C to +70 deg C |
| Power Consumption | Local Bus Power 12 VDC at 300 mA |
| Tariff Code | 8537101190 |
| Airborne Contaminants | ISA-S71.04-1985 Airborne Contaminants Class G3 |
| Shock Resistance | 10 g half sine wave for 11 msec |
| Vibration Resistance | 1 mm peak to peak from 2 to 13.2 Hz; 0.7 g from 13.2 to 150 Hz |
DCS Serial Communication and Interface Characteristics
The Emerson VE4006P2 provides serial communication functions for DeltaV system architectures through the KJ3241X1-BA1 hardware configuration. The module transfers serial data between connected field devices and the control system communication layer.
Additionally, Emerson DeltaV interface modules support structured process communication environments where protocol handling, signal conditioning, and channel isolation requirements apply. The VE4006P2 hardware design allows integration with serial communication paths while maintaining defined local bus power requirements.
The module operates from a 12 VDC local bus supply with a 300 mA current load. Furthermore, the hardware enclosure and circuit design meet industrial environmental requirements, including ISA-S71.04-1985 Class G3 airborne contamination conditions.
Frequently Asked Questions
Q: What power supply does the Emerson VE4006P2 require?
A: The VE4006P2 receives local bus power at 12 VDC with a specified current consumption of 300 mA.
Q: What environmental temperature range does the VE4006P2 support?
A: The module operates within an ambient temperature range from -40 deg C to +70 deg C.
Q: What installation environment requirements apply to the VE4006P2?
A: The module requires installation conditions that comply with its specified shock, vibration, and airborne contaminant limits.
Field Installation Guidelines
Install the Emerson VE4006P2 in the designated DeltaV system carrier or interface assembly according to Emerson hardware installation procedures.
Verify that the local bus power supply provides 12 VDC before connecting the module. Confirm correct seating of the module connector and avoid mechanical stress during insertion or removal.
Maintain proper cable routing practices for serial communication wiring. Keep signal cables separated from high-current power conductors to reduce electrical interference. Connect cable shields according to the system grounding design and maintain consistent grounding points.
Before system startup, inspect module mounting, connector engagement, environmental conditions, and communication wiring continuity.
