Overview
The Honeywell CC-PSV201 delivers high-performance control as a Servo Valve Positioner Module (SVPM), ensuring precise operation in turbomachinery applications. Moreover, as part of the Experion® Series C I/O family, it connects directly with the C300-20msCEE controller, which enables robust and reliable servo valve management.
This Series C I/O module features an onboard PID positioning loop that actively positions the servo valve. In addition, it accepts LVDT, RVDT, or 4-20 mA feedback signals from the control valve. Simultaneously, it receives demand set points from the C300-20msCEE controller and calculates the necessary current output to drive the servo valve coil. Consequently, the module maintains accurate control over valve position throughout operation.
Specification
| Parameter | Specification | ||
| Input/Output Model | CC-PSV201-Servo Valve Positioner Module | ||
| CC-TSV211 | Redundant | 18″ | |
| Servo Output | |||
| Output Type | Bipolar current (Ranges:10,20,40,80,160,320 mA) Unipolar current(Ranges:50,300 mA) | ||
| Output Channels | 2 | ||
| Dither | 0-10%of FS,25-60 Hz | ||
| Output Temperature Drift | 300 ppm per deg C | ||
| Output Current Lineaity | 0.325% | ||
| Resolution | 16-bit DAC | ||
| Maximum Resistive Load (24 Vsupply=22 VDC through 28 VDC) | Maximum cil resistance allowed for different current ranges with this interface are available in Honeywell DFS document | ||
| Maximum Open Circuit Voltage | ±14V | ||
| Gap(0 mA)of Output to Field on Switchover | 15mS maximum | ||
| LVDT Interface | |||
| Input/Feedback | 3/4/5/6 wires LVDT feedback signals,8VRMS max.,2.5-3.2 KHz | ||
| Excitation | 8VRMS max,2.5-3.2 KHz(max.internal excitation is 50 mA) | ||
| Frequency Stability | 2.5-3.2 KHz±5Hz from set value | ||
| Channels | 2 | ||
| Galvanic Isolation(any input terminal voltage referencedto common) | ±500 VDC | ||
| Isolation Technique | Isolation transformer | ||
| A/D Converter Resolution | 16-bits | ||
| Input/Output Range(1) | 8V RMS max,2.5-3.2 KHz | ||
| Input Impedance(voltage inputs) | Impedance>25 Kohm(2.5 KHz to 3.2 KHz) | ||
| Input Scan Rate | 2.5mS | ||
| Hardware Accuracy(@CMV=0V) | <1% | ||
| Analoq Inputs | *Al&LVDT signals are mutually exclusive | ||
| Input Type | Voltage,current (2-wire or self-powered transmitters) | ||
| Input Channels | 2 | ||
| Common Mode Voltage,DC to 60 Hz | -6 to +5V peak | ||
| A/D Converter Resolution | 16-bits | ||
| Input Range(1) | 0 to 5V,1 to 5V,0.4 to 2V,4-20 mA(through 250Ω) | ||
