Bently Nevada 102242-00-05-50 Vibration Transmitter

Hardware Specifications

Signal and Application Notes

A 4-20 mA output can transmit a measured process variable to a compatible PLC, DCS, or monitoring input. The receiving system must use the correct input type and configured engineering range. The supplied information does not establish how this model scales vibration into the current signal or whether the frequency range describes the sensor bandwidth, measurement range, or another operating parameter.

Configuration and Selection

Before selecting this part as a replacement, verify the complete part number against the equipment nameplate and the installed monitoring system. In particular, confirm the sensor type, measurement variable, signal conditioning requirements, supply voltage, and output characteristics. A matching 4-20 mA signal alone does not establish electrical or mechanical compatibility.

Frequently Asked Questions

Q: Does the 102242-00-05-50 provide a 4-20 mA output?

A: The supplied product information lists a 4-20 mA output. Confirm this specification against the original manufacturer documentation before connecting the device to a controller input.

Q: Is the measurement range confirmed as 0-1000 Hz?

A: The supplied data lists 0-1000 Hz, but this value has not been independently verified for the exact model. Confirm the measurement range and measurement variable before using it to configure vibration monitoring limits.

Q: Can this transmitter connect directly to a PLC or DCS?

A: Connection may be possible if the receiving input matches the device’s electrical output and signal requirements. Verify the wiring, power supply arrangement, signal scaling, and input compatibility before commissioning.
